NO

Items

Criteria

Remarks

2.1

Typical Capacity 典型容量

2100mAh

Discharge:0.2CmA cut-off voltage:9.0V 0.2C放电至9.0V截止

Minimum Capacity 最小容量

2050mAh

2.2

Energy 能量

23.31Wh

2.3

Nominal Voltage 标称电压

11.1V

2.4

Open Circuit Voltage出厂电压

11.1~11.8V

2.5

Internal Impedance 内阻

≤20mΩ

AC 1KHz after standard charge 标准充电后 AC 1KHz测试

2.6

Charge voltage 充电电压

12.6V

2.7

Standard charge current 标准充电电流

2100mA

1.0C

2.8

Max. charge current 最大充电电流

4200mA

2.0C

2.10

Max. discharge current 最大放电电流

31.50A( 15.0C)

持续 Cont Discharge Current

63.0A (30.0C)

瞬间Burst Discharge Current

2.11

Discharge cut-off voltage 放电截止电压

9.0V

2.12

Operating Temperature

工作温度

0~+45℃

Charging 充电

-10~+50℃

Discharging 放电
